Add Intelligence to Your Collaboration System

The IKON 200 combines a full HD camera with powerful speakers and microphones that makes it a complete solution for any small conference room or executive office business video conferencing system Built-in intelligence Auto framing enables the camera to track the attendees anywhere
in the room.

Wide Angle View

1200 Field of view ensures all persons in the room fit into the frame so you don’t miss out on the group

Video

• Image Sensor: SONY IMX 415-8MP

• IRIS: F2.2

• Focal Length: f=2.1mm

• Digital Zoom: 4X & ePTZ support

• FOV: 120°

• Video Output Format: [email protected]/25, 1920×[email protected], 1280×[email protected],640×[email protected]

• Min Focus Distance: 50cm

• Min Illumination: 50Lux

• Exposure: Auto, Manual, Shutter Priority

• White Balance: Auto, Manual, Trigger

• Digital Noise Reduction: 2D, 3D

• Image Flip: Flip, Mirror

• Intelligent Function: Auto Framing

Integrated Audio

• Speaker: 5W Speaker Output

• Microphone: Built-in High Sensitivity 4 Microphones Array

• Frequency Response: 100Hz – 24000Hz

• Sensitivity: 96dB [email protected] KHz

• SNR: 65dB

• Other Features: Echo Cancellation, Dynamic Noise Reduction, Auto gain control, Full Duplex HD call, 180 Degree Pick-up Range and Inbuilt DSP Audio Processing

Interfaces

• USB: USB 3.0 Type-C & USB Type-A

• Power: DC Power Supply

General

• Power: DC12V

• Power Consumption: <8W

• Relative Temperature: 0°C ～ + 40°C

• Working Humidity: 10%～ 90%

• Storage Temperature: -20°C ～ +60°C

• Dimensions: 500 mm × 81 mm × 55 mm（L×W×H）

• Net Weight: 1450g

• Color: Black
