PTZ Camera

• Image Sensor: 1/2.8” 4K Sony Exmor CMOS
• Effective Picture Elements: 8 Megapixels
• Output Resolutions: Up to 4K/30
• Minimum Illumination: 0.46 lux (IRE50, F1.6, 30fps)
• S/N Ratio: ≥ 50 dB
• Gain: Auto
• TV Line: 1500 (Center)
• Shutter Speed: Auto
• Exposure Control: Auto
• White Balance: Auto, Manual
• Hybrid Optical Zoom: 4.5X
• Digital Zoom: 4X
• Total Zoom: 18X
• Viewing Angles: DFOV: 92°, HFOV: 81°, VFOV: 50°
• Viewing Area: Pan: 141°, Tilt: 78°
• Preset Positions: Up to 128*
• Camera Control – Interfaces: IP, USB*, Remote Control, AVer CP10 G2, Zoom Rooms Controller App
• Camera Control – Protocols: VISCA (IP)*, CGI (IP), USB*
• Image Processing: WDR, 3D/2D Digital Noise Reduction
• Power Frequencies: 50 Hz, 60 Hz

Fixed Camera

• Image Sensor: 1/2.5” 4K Sony Exmor CMOS
• Effective Picture Elements: 8 Megapixels
• Output Resolutions: Up to 4K/30
• Viewing Angles: DFOV: 120°, HFOV: 110°, VFOV: 75°
• Viewing Area: Pan: 170°, Tilt: 103°

Speaker

• Volume: 96 dB SPL at 0.5 Meter Peak
• Sensitivity: 81 ±2dB SPL at T/S Parameter
• Frequency Response: 110 Hz to 20 KHz
• Sample Rates: 48 KHz

USB

• Connector: USB 3.1
• Video Format: YUY2, MJPEG
• Audio Format: PCM
• Maximum Video Resolution: 4K 30fps
• USB Video Class (UVC): UVC 1.1
• USB Audio Class (UAC): UAC 2.0

Microphones

• Beamforming Elements: 14
• Pickup Range: 10 Meters
• Sensitivity: -35 ±1dB FS
• Frequency Response: 100 Hz to 12 KHz
• Acoustic Echo Cancellation (AEC): Yes
• Automatic Gain Control (AGC): Yes
• Noise Suppression: Yes
• Sample Rates: 24 KHz
• Expansion Microphone: Yes (Up to 1 Microphone)
• Expansion Speakerphone: Yes (Up to 1 Speakerphone)

Interfaces

• HDMI Out: 2
• HDMI In: 1
• USB: USB Type-A x 3, USB 3.0 Type-C* (DisplayPort Alternate Mode) x 1
• Network: RJ-45 x 1
• Line In: 1
• Audio In/Out: RJ-45 x 1
• Wi-Fi*: 802.11 a/b/g/n/ac
• Bluetooth®*: Bluetooth® Low Energy

General

• Operating System: Android™ 13
• Power Requirement: AC 100 – 240V to DC 12V/7.5A
• Power Consumption: 90W
• Dimensions (W x H x D): 790 x 129 x 138 mm
• Net Weight: 3.7 ±0.1 kg
• Application: Indoor
• Security: Kensington Slot
• Remote Control: Infrared
• Operating Conditions: Temperature: 0 °C to +40 °C, Humidity: 20% to 80%
• Storage Conditions: Temperature: -20 °C to +60 °C, Humidity: 20% to 80%

Web UI

• Live Video Preview: Yes
• Camera PTZ Control: Pan, Tilt, Zoom, Focus, Preset Control
• Camera/Image Adjustment: Exposure, White Balance, Picture
• Network Configuration: DHCP, IP Address, Gateway, Subnet Mask, DNS

AVer AI Technologies

• Onboard AI: Yes
• Video AI*: Smart Composition, Auto Framing
• Audio AI*: Voice Tracking, Audio Fence, Beamforming Technology

Certifications

• Zoom
  • Built-in Zoom Rooms
  • Functions: Auto-Framing, Multi-Focus Framing, Speaker Focus, Multi-Stream
• (Smart Gallery)*

Compatibility

Software & Apps*: Zoom, Microsoft® Teams, Skype, Google Meet™, Intel® Unite™,

RingCentral, BlueJeans, V-Cube, LiveOn, CyberLink U Meeting®, TrueConf, Adobe®

Connect, Cisco WebEx®, Fuze, GoToMeeting™, Microsoft® Lync™, Vidyo, vMix, WebRTC,

Wirecast, XSplit, V Cube

Optional Accessories

AVer CP10 G2 Collaboration Touch Panel, USB 3.0 Type-C to Type-C Cable, Expansion Speakerphone, Expansion Microphone, TV VESA Mount

Warranty*

• Camera: 3 years
• Accessories: 1 year

Package Contents

VB370A, Power Adapter, Power Cable, Remote Control, HDMI Cable, Tripod Screw (x2), Wall-Mount Bracket, Drilling Paper

Optional Accessories

AVer CP10 G2 Collaboration Touch Panel, USB 3.0 Type-C to Type-C Cable, Expansion Speakerphone, Expansion Microphone, TV VESA Mount
